VISINSPECT ONE 5400°K
LuxiRing is an innovative industrial lighting system integrating exclusive LuxiBright® technology. Providing directional, precise, and uniform illumination, LuxiRing enhances the detection of the finest details in your industrial components. Designed without unnecessary components, it eliminates glare and stray light, significantly improving the performance of your machine vision cameras. Available as a complete Lab Kit for testing or as individual components.
Discover LuxiRing, the next-generation industrial lighting system designed to meet the most demanding requirements of machine vision. Equipped with exclusive LuxiBright® technology, LuxiRing delivers perfectly directional, precise, and uniform illumination. Its unique design eliminates glare and stray light that can interfere with visual inspections, ensuring optimal detection of even the most intricate details of your components.
Unlike traditional LED lighting, LuxiRing is engineered with fewer components for maximum efficiency. Its innovative structure focuses light exactly where it is needed, without dispersion or glare, allowing your industrial cameras to capture images with exceptional sharpness and precision.
Whether you want to explore this technology with the complete Lab Kit or selectively integrate the components best suited to your needs, LuxiRing adapts to all industrial configurations.
Shipping: 2 to 4 weeks. The expected shipping date confirmation will be sent via email.
Additional information
| Radius Ring | Mini 40mm, 76mm High Angles, 76mm Low Angles, 160mm High Angle, 160mm Low Angle, Maxi 420mm |
|---|---|
| Controller | Included |
| Size L.E.S.S. Cable | 1m, 2m |
| Size M12 cable | 1.5m |
| Color temperature | 5400°K |
| Overdrive | x2,5 |
| Stroboscope responsiveness | <10 microseconds |
| Illumination modes | Continuous / Trigger / Strobe |
| Mechanical Interface | DIN Rail Adaptor (TS35) |
| Max. Energy Consumption | 19W (Overdrive), 12W (Nominal) |
| Electrical Interface | 24 VDC / GND / Trig In |
| Frame material | Anodised Aluminium |
| Mounting holes | M4 |
| Operating temperature | 0-40°C |
| IP Protection Index | IP30 |
| Weight | Mini <130g |
| Lighting technology | LuxiBright® |
| Controller Input Voltage | 24 VDC |
| Analog Dimming Control (30%-100%) | 0-10 VDC |
Resources
Datasheet
To learn more about our product, here you can download the technical datasheet of the VisInspect made by L.E.S.S. SA
Datasheet
To learn more about our product, here you can download the technical datasheet of the VISIAID made by L.E.S.S. SA
User manual
COMING SOON …
FAQ
This section is designed to provide answers to common questions and concerns, allowing you to easily find the information you need.
VISINSPECT
SYSTEM
Effortlessly control the light, from turning it on and off to adjusting the desired intensity, simply by rotating the button clockwise. Precision lighting at your fingertips.
Effortlessly control the light, from turning it on and off to adjusting the desired intensity, simply by rotating the button clockwise. Precision lighting at your fingertips.
The VisiAid frame fits easily over your glasses, with an integrated lighting fibre for clear vision without any shadow.
The VisiAid frame fits easily over your glasses, with an integrated lighting fibre for clear vision without any shadow.
The VisiAid Control Case, is designed for an easy attachment to your belt or pants using the built-in clip on the case's back.
The VisiAid Control Case, is designed for an easy attachment to your belt or pants using the built-in clip on the case's back.
Simply clip it to your own prescription glasses and enjoy ultra-bright new vision.
Simply clip it to your own prescription glasses and enjoy ultra-bright new vision.
